Cree XSPR Series Description
In addition to a low initial cost, the XSPR™ LED Street Light maintains the familiar look of the traditional cobrahead design and delivers substantial energy savings while reducing maintenance time and costs. The hassle-free design of the XSPR luminaire includes simplified mounting solutions, horizontal tenon mount or adjustable arm, that allow for fixture leveling of +/-5°. Our NanoOptic® Precision Delivery Grid™ optic achieves better optical control than traditional street lighting fixtures and efficiently delivers white uniform light for safer-feeling communities.
Product Specifications
Power Rating | 17W to 54W |
Lumen Output | 1,965lm to 5,613lm |
CCT | 5700K/4000K |
IP Rating | IP66 |
CRI | >70 |
Power Factor | >0.95 at full load |
Input Voltage | 220-240V,50/60Hz |
Total Harmonic Distortion | <20% at full load |
Surge Suppression Protection | Integral 10kV |
Weight | 5kg |
Warranty | 5 Years |
Downloads
XSPR Spec Sheet | |
XSPR IES Files |
